          MF Series PE Pulverizer Machine

          MF Series PE Pulverizer Machine



             MF series mill can be used for economical and efficient grinding of various thermoplastic materials at normal temperature, such as HDPE MFPE LLDPE LDPE PP PVC ABS PA PC and so on. Produces high-quality powders (free-flowing powders with high bulk density) for rotomolding applications. Relative to output and energy consumption, the MF series is the most economical air-cooled mill. The smaller footprint (compact size) makes it ideal for producers or processors.



          The brand-new MF series PE pulverizer belongs to the Disc-type pulverizer series, which disc diameter from 350mm to 800mm.This pulverizer is high speed, precision grinders for the processing of medium hard, impact resistant and friable materials, for example PE、PVC、PP、ABS、PA、EVA、PET、PS、PPS、EPS、PC、Foam、Cow leather and so on.
          One of the main fields of use of HUIBANG MF series plastic pulverizer is the pulverization of PE for rotomolding applications. In this process, a screening machine is necessary to ensure the right output size.


          Area of application:

          • Size reduction of plastic

          • Engineering plastic compounding

          • Extruded plastic recycling

          • Composite plastic production

          • Rotomolding powder production and recycling

          • Pipe & sheet crushing and recycling





          • Save and simple adjustment of cutting gap

          • Low drive power and High throughput

          • Easy to maintain and control

          • Automatically regrinding coarse powder

          • Water and wind dual cooling system

          • Various Disc configurations available













          Model

          MF-400

          MF-500

          MF-600

          MF-800

          Diameter of disc(mm)

          ¢400

          ¢500

          ¢600

          ¢800

          Main motor power (kw)

          22

          37

          45/55

          75/110

          Capacity(kg/h)

          50-300

          80-500

          120-800

          200-1200

          Note: The output is affected by material properties , feed size, powder size and so on.
